Nouvel absorbeur à film tombant en graphite à trous ronds
The New Round Block Hole Graphite Falling Film Absorber efficiently absorbs gases using graphite blocks with hole structures, enhancing heat and mass transfer.
Paiement:
TT L/C PayPal Westunion MoneygramOrigine du produit:
China， Anhui provincePort d'expédition:
ShanghaiDélai de mise en œuvre:
1 MonthMOQ:
1Emballer:
Wooden caseCouleur:
customziedMatériel:
GraphiteTempérature de travail:
≤170℃Pression de travail:
Vertical≤0.1Mpa,Horizontal≤0.4Mpa
Product review
The structure represents a modified version of the YKX graphite falling film absorber. The absorption heat exchange element features a structure without a central through hole. It is characterized by its compactness, relatively high material utilization rate, and is a gas absorption equipment with outstanding performance.
Product advantages
The New Round Block Hole Graphite Falling Film Absorber provides outstanding corrosion resistance, high thermal conductivity, efficient gas absorption capabilities, durability, and improved heat transfer performance.
Structural diagram
| Parts details | |
| 1 | Air inlet |
| 2 | Graphite gas-liquid mixing chamber |
| 3 | Liquid inlet |
| 4 | Graphite pressure stabilizing ring |
| 5 | Graphite distribution head |
| 6 | Vent |
| 7 | Cooling water outlet |
| 8 | Equipment support |
| 9 | Graphite heat exchange block |
| 10 | Cooling water inlet |
| 11 | Drain port |
| 12 | Gas liquid separation chamber |
| 13 | Tail gas outlet |
| 14 | Acid outlet |
Drawing Specification Table for Tube
| Model | a.e Tube | b.c Tube DN | f.g Tube DN | d Tube | h Tube | |||
| D1 | D2 | D3 | D4 | D5 | D6 | |||
| KXG40 | 65 | 160 | 50 | 20 | 150 | 295 | 75 | 180 |
| KXG50 | 75 | 180 | 65 | 20 | 200 | 350 | 100 | 210 |
| KXG60 | 100 | 210 | 80 | 20 | 250 | 400 | 125 | 240 |
| KXG70 | 100 | 210 | 100 | 25 | 250 | 400 | 200 | 350 |
| KXG80 | 125 | 240 | 100 | 25 | 300 | 460 | 250 | 400 |
| KXG90 | 125 | 240 | 150 | 25 | 300 | 460 | 250 | 400 |
